1414 N4 PH Series Hammond MFG Painted Steel Enclosures
1414 N4 PH Series Hammond MFG Painted Steel Enclosures 1414 N4 PH Series Hammond MFG Painted Steel Enclosures Specs
$54.33 $59.95
Product Information
Part Number: 1414N4PHA
  • Description
  • Specifications
  • NEMA Ratings
  • Designed for use as instrument enclosures, electric, hydraulic or pneumatic control housings, electrical junction boxes or terminal wiring enclosures. Provides protection where equipment may be hosed down or otherwise be very wet, or in outdoor applications for full weather protection.

    Standards

    • UL 508A Type 3R, 4, 12 and 13
    • CSA Type 3R, 4, 12 and 13
    • NEMA Type 3R, 4, 12 and 13
    • IEC 60529, IP66
    • Specifications

      Please click a part number below to view the product specifications.

      Product Dimensions

      Part Number

      4x4x3 in. 1414N4PHA
      6x4x3 in. 1414N4PHC
      8x6x3.5 in. 1414N4PHG
      6x6x4 in. 1414N4PHE
      10x8x4 in. 1414N4PHI
      10x8x6 in. 1414N4PHI6
      12x10x5 in. 1414N4PHK
      12x12x6 in. 1414N4PHL6
      14x12x6 in. 1414N4PHM6
      16x14x6 in. 1414N4PHO6
      14x12x8 in. 1414N4PHM8
      16x14x10 in. 1414N4PHO10
    • Type 3R

      Enclosures constructed for either indoor or outdoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (rain, sleet, snow); and that will be undamaged by the external formation of ice on the enclosure.

      Type 4

      Enclosures constructed for either indoor or outdoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt and windblown dust); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (rain, sleet, snow, splashing water, and hose-directed water); and that will be undamaged by the external formation of ice on the enclosure.

      Type 12

      Enclosures constructed (without knockouts) for indoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt and circulating dust, lint, fibers, and flyings); and to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (dripping and light splashing).

      Type 13

      Enclosures constructed for indoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt and circulating dust, lint, fibers, and flyings); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (dripping and light splashing); and to provide a degree of protection against the spraying, splashing, and seepage of oil and non-corrosive coolants.
