Eclipse Series Hammond MFG Stainless Steel Enclosure
Eclipse Series Hammond MFG Stainless Steel Enclosure Eclipse Series Hammond MFG Stainless Steel Enclosure Specs
$445.95 $477.84
Product Information
Part Number: EN4SD12126SS
  • Description
  • Specifications
  • NEMA Ratings
  • Designed to enclose electrical and/or electronic equipment and protect against harsh, industrial environments for wall-mount applications. Impressive styling features like hidden hinges and attractive latching systems make the Eclipse a suitable addition to any high-tech equipment installation. A wide range of sizes and practical accessories make this product line a complete package.

    Standards

    • UL 508A Type 3R, 4, 4X and 12
    • CSA Type 3R, 4, 4X and 12
    • NEMA 3R, 4, 4X, 12 and 13
    • IEC 60529, IP 66
  • Specifications

    Please click a part number below to view the product specifications.

    Product Dimensions

    Part Number

    12x12x6 in. EN4SD12126SS
    16x12x6 in. EN4SD16126SS
    16x16x6 in. EN4SD16166SS
    16x20x6 in. EN4SD16206SS
    20x16x6 in. EN4SD20166SS
    20x20x6 in. EN4SD20206SS
    24x20x6 in. EN4SD24206SS
    16x12x8 in. EN4SD16128SS
    16x16x8 in. EN4SD16168SS
    16x20x8 in. EN4SD16208SS
    20x16x8 in. EN4SD20168SS
    20x20x8 in. EN4SD20208SS
    20x24x8 in. EN4SD20248SS
    24x16x8 in. EN4SD24168SS
    24x20x8 in. EN4SD24208SS
    24x24x8 in. EN4SD24248SS
    24x30x8 in. EN4SD24308SS
    30x20x8 in. EN4SD30208SS
    30x24x8 in. EN4SD30248SS
    30x30x8 in. EN4SD30308SS
    36x24x8 in. EN4SD36248SS
    36x30x8 in. EN4SD36308SS
    42x36x8 in. EN4SD42368SSR
    48x36x8 in. EN4SD48368SSR
    16x12x10 in. EN4SD161210SS
    16x16x10 in. EN4SD161610SS
    16x20x10 in. EN4SD162010SS
    20x16x10 in. EN4SD201610SS
    20x20x16 in. EN4SD202010SS
    20x24x10 in. EN4SD202410SS
    24x16x10 in. EN4SD241610SS
    24x20x10 in. EN4SD242010SS
    24x24x10 in. EN4SD242410SS
    24x30x10 in. EN4SD243010SS
    30x20x10 in. EN4SD302010SS
    30x24x10 in. EN4SD302410SS
    30x30x10 in. EN4SD303010SS
    30x30x12 in. EN4SD303012SS
    36x24x10 in. EN4SD362410SS
    36x30x10 in. EN4SD363010SS
    36x36x10 in. EN4SD363610SSR
    42x30x10 in. EN4SD423010SSR
    42x36x10 in. EN4SD423610SSR
    48x24x10 in. EN4SD482410SS
    48x36x10 in. EN4SD483610SSR
    60x36x10 in. EN4SD603610SSR
    20x20x12 in. EN4SD202012SS
    24x24x12 in. EN4SD242412SS
    30x24x12 in. EN4SD302412SS
    36x24x12 in. EN4SD362412SS
    36x30x12 in. EN4SD363012SS
    36x36x12 in. EN4SD363612SSR
    42x36x12 in. EN4SD423612SSR
    18x36x12 in. EN4SD483612SSR
    60x36x12 in. EN4SD603612SSR
    72x36x12 in. EN4SD723612SSR
    30x24x16 in. EN4SD302416SS
    36x30x16 in. EN4SD363016SS
    48x36x16 in. EN4SD483616SSR
  • Type 3R

    Enclosures constructed for either indoor or outdoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (rain, sleet, snow); and that will be undamaged by the external formation of ice on the enclosure.

    Type 4

    Enclosures constructed for either indoor or outdoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt and windblown dust); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (rain, sleet, snow, splashing water, and hose-directed water); and that will be undamaged by the external formation of ice on the enclosure.

    Type 4X

    Enclosures constructed for either indoor or outdoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (windblown dust); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (rain, sleet, snow, splashing water, and hose directed water); that provides an additional level of protection against corrosion; and that will be undamaged by the external formation of ice on the enclosure.

    Type 12

    Enclosures constructed (without knockouts) for indoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt and circulating dust, lint, fibers, and flyings); and to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (dripping and light splashing).

    Type 13

    Enclosures constructed for indoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt and circulating dust, lint, fibers, and flyings); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (dripping and light splashing); and to provide a degree of protection against the spraying, splashing, and seepage of oil and non-corrosive coolants.
