H1 Series Hammond MFG Rack Enclosures
H1 Series Hammond MFG Rack Enclosures H1 Series Hammond MFG Rack Enclosures Black Panel H1 Series Hammond MFG Rack Enclosures Stacked H1 Series Hammond MFG Rack Enclosures H1 Series Hammond MFG Rack Enclosures White Panel H1 Series Hammond MFG Rack Enclosures Lock H1 Series Hammond MFG Rack Enclosures
$2,117.75 $2,269.21
Product Information
Part Number: H12442U42BK
  • Description
  • Specifications
  • More Info
  • The H1 series is designed as your most complete offering for Server, Network, and Data Storage applications. This series incorporates Hammond Manufacturing’s practical open-design and manufacturing principles with legendary service, support, and reliability. H1 cabinets feature an array of enhancements over traditional cabinets, with cooling performance and enhanced security features demanded by today’s IT manager.

  • Specifications

    Please click a part number below to view the product specifications.

    Product dimensions

    Part Number

    80.37x24x42 in. H12442U42BK
    80.37x30x42 in. H13042U42BK
    80.37x31.5x42 in. H13142U42BK
    80.37x24x48 in. H12442U48BK
    80.37x30x48 in. H13042U48BK
    80.37x31.5x48 in. H13142U48BK
    85.65x24x42 in. H12445U42BK
    85.65x30x42 in. H13045U42BK
    85.65x31.5x42 in. H13145U42BK
    85.65x24x48 in. H12445U48BK
    85.65x30x48 in. H13045U48BK
    85.65x31.5x48 in. H13145U48BK
    90.87x24x42 in. H12448U42BK
    90.87x30x42 in. H13048U42BK
    90.87x31.5x42 in. H13148U42BK
    90.87x24x48 in. H12448U48BK
    90.87x30x48 in. H13048U48BK
    90.87x31.5x48 in. H13148U48BK
    97.9x24x42 in. H12452U42BK
    97.9x30x42 in. H13052U42BK
    97.9x31.5x42 in. H13152U42BK
    97.9x24x48 in. H12452U48BK
    97.9x30x48 in. H13052U48BK
    97.9x31.5x48 in. H13152U48BK
  • TAA Compliant.

    RoHS Compliant.

    Standards

    • Constructed in 14-gauge steel
    • .48" Depth cabinet includes:
      • Four (4) large cable entry knockouts at the rear top/bottom
      • Two (2) large cable entry knockouts at the front/top
    • Grounding studs bonded to frame, side panels and doors.
      • Front and rear studs conform to PET.
    • UL Listed 2416 rated for up to 3,000 lbs (1,360 kg) static load rating.
    • Rated for up to 2,200 lbs (997.90 kg) rolling caster load rating. Heavy duty casters are also available.
    • Finished in textured black or white powder paint.
    • TAA Compliant.
    • RoHS Compliant.
    • Manufactured in North America.
