Hammond PCJHFPP86 Adjustable Swing Panel Kit for PCJ864 Enclosures

Specifications

Specifications

Product Type	Enclosure Accessories
Material	Aluminum

Description

The Hammond PCJHFPP86 hinged aluminum swing panel kit fits the PCJ864 enclosure base, including its solid/clear screw-cover and feet/flange configurations. Nominal enclosure size: 8 × 6 × 4 inches.

• Adjustable depth using corner sliders.
• Installs for right- or left-hand swing without drilling.
• 0.09 inch aluminum panel; mounting hardware included.

Enclosure sold separately. Representative series image shown; part-specific drawing and CAD files are under Downloads.

Downloads

Downloads for this variant

• PCJHFPP86 dimensional drawing (PDF)
• Series specifications (PDF)
• PCJHFPP86 2D CAD (DXF ZIP)
• PCJHFPP86 3D CAD (STEP ZIP)
