HJ Series Hammond MFG Painted Steel Enclosures
HJ Series Hammond MFG Painted Steel Enclosures HJ Series Hammond MFG Painted Steel Enclosures HJ Series Hammond MFG Painted Steel Enclosures HJ Series Hammond MFG Painted Steel Enclosures Specs
$39.64 $42.47
Product Information
Part Number: HJ443LP
  • Description
  • Specifications
  • NEMA Ratings
  • Designed for use as instrument enclosures, electric, hydraulic or pneumatic control housings, electrical junction boxes or terminal wiring enclosures. Provides a degree of protection from falling dirt, dust, oil and water.

    Standards

    • UL 508A Type 3R, 4, 12 and 13
    • CSA Type 3R, 4, 12 and 13
    • NEMA Type 3R, 4, 12 and 13
    • IEC 60529, IP66
  • Specifications

    Please click a part number below to view the product specifications.

    Product dimensions

    Part Number

    4x4x3 HJ443LP
    6x4x3 HJ643LP
    8x6x3.5 HJ863LP
    4x4x4 HJ444LP
    6x4x4 HJ644LP
    6x6x4 HJ664LP
    10x8x4 HJ1084LP
    12x10x5 HJ12105LP
    14x12x6 HJ14126LP
    16x14x6 HJ16146LP
    14x12x8 HJ14128LP
    16x14x10 HJ161410LP
  • Type 3R

    Enclosures constructed for either indoor or outdoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (rain, sleet, snow); and that will be undamaged by the external formation of ice on the enclosure.

    Type 4

    Enclosures constructed for either indoor or outdoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt and windblown dust); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (rain, sleet, snow, splashing water, and hose-directed water); and that will be undamaged by the external formation of ice on the enclosure.

    Type 12

    Enclosures constructed (without knockouts) for indoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt and circulating dust, lint, fibers, and flyings); and to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (dripping and light splashing).

    Type 13

    Enclosures constructed for indoor use to provide a degree of protection to personnel against access to hazardous parts; to provide a degree of protection of the equipment inside the enclosure against ingress of solid foreign objects (falling dirt and circulating dust, lint, fibers, and flyings); to provide a degree of protection with respect to harmful effects on the equipment due to the ingress of water (dripping and light splashing); and to provide a degree of protection against the spraying, splashing, and seepage of oil and non-corrosive coolants.
