Integra Premium Series Polycarbonate Enclosure with Hinge Opaque Screw Cover and Mounting Flange

Specifications

Specifications

Product Type	Enclosures
Material	Polycarbonate
Series	Integra Premium Series
Application	Outdoor
IP Equivalent	IP68
Height	6
Width	6
Depth	2
Inner Dimensions	6 x 6 x 2.38
Cover Type	Hinged Cover, Opaque, Screw Cover
Mount Type	Wall Mount
Mounting Plate Included	No

Description

Premium Line

• Polycarbonate Enclosures, Premium Line
• UL/cUL NEMA TYPE 6P IP68
• Mounting Flange
• Screw Closure
• Screw/Hinged
• Opaque cover

A high-impact polycarbonate enclosure designed for rugged environments. The enclosure features a screw closure with an opaque cover and mounting flanges. It meets UL/cUL NEMA TYPE 6P and IP68 ratings, providing strong protection against dust and water ingress. The enclosure has a flame rating of UL 5VA and outdoor UV exposure rating of F1. It is UL-50/c-UL listed (files #E229365, #E207562). The design includes brass inserts for easy mounting, a hydro-phobic urethane gasket for a reliable seal, and a light gray gloss finish.

Protection Rating: UL/cUL NEMA TYPE 6P IP68

Accessories

Additional Accessories

• Integra Premium Series Mounting Panels — $13.95
• Integra Premium Series Swing Panels and Swing Panel Kits — $14.85
• Integra Din Rail Kits — $15.84
• Integra Pole Mounting Kit — $46.50

NEMA Rating

• 6P
